AC-MC-FLEX FITTINGS

BIG BITE-SADDLE TYPE COMBINATION COUPLINGS

APPLICATION

To connect Flex, AC, and MCI cables to EMT Conduit.

FEATURES

  • One piece tubular construction affording extra strength
  • Dual gripping saddle clamps
  • Saddle clamp rides up & down on screw for ease of installation
  • Robertson Head Screws

STANDARD MATERIALS

Tubular Steel

STANDARD FINISH

Zinc Plated

UL LISTED

1/2” thru 3/4”
E198258

image description
Catalog Number Trade Size Unit Pack Master Pack UPC
DBS-38 3/8” 50 500 90128
DBS-50 1/2” 25 100 90129
DBS-75 3/4” 10 100 90130
